46" Restaurant/CafeShop/Hotel/MeetingRoom IR Touch Tabl
ETK-0460I-MWD

Product name: 46 inch Infrared Touch Table Kiosk
Model number: ETK-0460I-MWD
Touch points: Optional 2/4/6/10 points
Popular size:42”/46”/55”/65”
Application: Restaurant/Cafe shop/Starbucks/Hotel/Conference Room

Main features:

1.Language: English/Spainish/Portuguese/Germany/French/Russia/Sweden/Polish/Greek etc.
2.Support screen division
3.Support scrolling text
4.Automatic on/off functions
5.Recovering playing from where it was when the power recovery
6.Update contents by insert an USB flash driver
7.Support 3G moudule
8.Advertising update by network/ download to local disk
9.Support software upgrade
10.Graceful Aluminum & metal platecase design with durable tempered glass protect
11.High resolution display with brand LED ( Samsung/LG/AUO A+grade)
12.More convenient & fun with IR touch screen to realize multi-touch function

General Specification
Model		ETK-0460I-MWD
Display dimension		46 inch
LED panel brand		SAMSUNG/LG/AUO A+ grade
LED Panel parameter	Panel type	46 inch LED
	Resolution	1920*1080
	Color	16.7m
	Brightness	450cd/㎡
	Contrast ratio	5000:1
	View Angle	89/89/89/89（left/right/top/bottom）
Video mode	decode	3D digital comb filter & 3D noise reduction function. Double 3D dynamic video scanning and compensation line by line.  1920*1080 high definition decode
Audio/Speaker character	Speaker type	Using the seperable speakers
	Speaker max wattage	5W*2 8Ω
	Audio speciality	Stereo,bilingual,surround sound
Touch system parameter
Computer hardware configuration	Industrial mother board	H61 industrial level mother board (optional)
	CPU	InterI5
	Memory bank	4GB
	Hard disk	500GB
Major input interface	VGA	1 port
	USB2.0 interface	4 ports
	HDMI input	1 port
	Ethernet	1 port, wired reticle/WIFI /3G (optional)
Touch OS	Integrated mode	Seamless built-in, Embemdded
	Touch technology	Infrared touch
	Way of writing	Finger/pen/any non-transparent object
	Response time	5ms
	Location accuracy	±1.5mm
	Touch resolution	4096×4096
	Valid touch identification	＞5mm
	Computer identification	automatic
	Touch screen	2/4/6/10 points IR touch screen (optional)
Operation system		win 7 64bit
Installation		desktop with table stand
Input power		110~240V 50HZ/60HZ
Accesorries		Warranty card, certification, power line, lock keys
Machine power		<250W
Save electricity power consumption		<1W
Enviromental factors		Operation temperature: 10℃～40℃
		Operation humidity: 20%～80%
		Storage temperature: -20℃～40℃
		Storage humidity: 5%～95%
		Altitude:Lower than 1600 meters
Main structure &  dimension	Case material	Metal plate + Tempered glass front-panel
	external dimension  (L*W*T)	1325.6*796.4*122.5mm
	Package dimension  (L*W*T)	1375.6*846*172.5mm
	Net weight (only table kiosk)	55KG
	Gross weight  (total with package  and accessories)	62KG

Accessories:
Product qualification Certificate x1
Power line ( EURO-STANDARD & AMERICAN STANDARD) x1
Protect plastic foam x1
User manual x1
