| Model No: | ETK-0230C-WF |
| Industrial CPU | Intel J1900 / i3, 4G+64G |
| OS Supported | Win7, Win8, Win10 |
| LCD display | 23 inch TFT- LED backlight |
| Active Area (mm) | 509.1(V)*286.4(H) |
| Resolution | 1920*1080 |
| Support Colors | 16.7M |
| View Angle | 178/178 |
| Contrast ratio | 1000:1 (Typ.) |
| Brightness | 250 cd/m² (250-1000 Optional) |
| Response Time | 5ms (Typ.) |
| Touch screen | Capacitive (PCAP) Touch screen |
| Touch points | 10 points |
| Touch response time | <5ms |
| POS Machine | Support card reader and hand-held POS. (Optional) |
| Barcode Scanner |
Laser scan barcode multiple line and multi-direction recognition technology |
| Receipt printer | Support 80mm thermal printer with auto cutter and alarm function. (Optional) |
| Camera | Optional |
| Power Supply | AC 100-240 V, 50/60 Hz |
| Power Consumption | <40W |
| MTBF | 50,000 hours |
| Dimension (mm) | 555mm(W)*1425mm(H)*355mm(D) |
| Net weight | 55KG |
| Kiosk Cabinet |
Durable cold rolled steel, high & Low temperature resistance, slim and smart design, easy to install, Moisture proof, Anti-rust, Anti-acid, Anti-dust, Static free |
| Material | Aluminum Alloy + Sheet metal |
| Protection | IP65 in surface |
|
Temperature Humidity |
Operating: 0 to 50°C, storage :-20 to 60°C Operating: 5% to 90% , storage :5% to 90% |
| Custom Option | The above configuration can be customized |
